KA186FA
| 型号 Model | KA186FA |
| 额定输出 Rated output(HP/rpm) | 7.9HP/3000, 8.6HP/3600 |
| 额定输出 Rated output(KW/rpm) | 5.7KW/3000, 6.3KW/3600 |
| 发动机型号 Engine type | Single-cylinder, vertical, four-stroke, air-cooled, direct injection |
| 缸径*尺寸 Cylinder Diameter*stroke(mm) | 86X72 |
| 排量 Piston displacement (L) | 0.418 |
| 压缩比 Compression ratio | 19 |
| 最大静音 Max. no-load speed(r/min) | 108% of Rated rotary speed |
| 最小静音 Min. no-load speed(r/min) | 1300 |
| 润滑方式 Lubrication system | 压力飞溅式 Pressure splash complex Type |
| 起动方式 Engine starting system | 反冲手拉启动/电启动Recoil starter or Electric starter |
| 输出接线 Output terminal rotation | AnticlockWise |
| 燃油型号Fuel oil model | Summer: 0#, Winter: -10# |
| 油箱容量 Fuel tank capacity (L) | 5.5 |
| 燃油耗 Fuel consumption rate(g/kW. h) | 275/3000 280/3600 |
| 耗油率 Oil consumption rate(g/kW. h) | 4.08 |
| 润滑油牌号 Oil grade | CD grade or SAE10W-30, 15W-40 |
| 气门间隙 Valve clearance(cold state) mm | 0.10-0.15 |
| 润滑油容量 Lube oil capacity (L) | 1.65 |
| 启动马达 Starting motor (V, kW) | 12V 0.8kW |
| 充电发电机 Charging generator(V, A) | 12V 3A |
| 电池容量 Battery capacity(V, AH) | Above 12V-36AH |
| 尺寸 Dimension (L*W*H)(mm) | 522*522*578 |
